In stock
Product Details
  • Ideal for EFI applications up to 4000 HP on gas and 2000+ HP on Methanol where an approximate 7 GPM fuel pump is required. Ideal for use in Import Drag Racing, “Drag Week,” or True Street type race cars.
  • Intermittent-duty use only.
  • Ultra high efficient electric motor assembly compatible with 12 volt supply
  • Self priming
  • -16 o-ring port inlet and -12 o-ring port outlet
  • Billet aluminum, MIL-SPEC anodized housing
  • Balance-loaded 10 vane steel pump element provides consistent flows throughout the pressure range up to 100 PSI
  • Uses the same proven Teflon lip seal as all other Weldon pumps which eliminates any possibility of leaking or failure
  • Compatible with all race fuels
  • 10.5 lbs
  • Gasoline
  • Methanol
  • Diesel
  • Ethanol
  • All race fuels
